Electricity generation and transmission concept

The purpose of the electric transmission system is the interconnection of the electric energy producing power plants or generating stations with the loads. A three-phase AC system is used for most transmission lines. The operating frequency is 60 Hz in the U.S. and 50 Hz in Europe, Australia, and part of Asia.

Electricity generation, transmission and distribution guides
Electricity generation, transmission and distribution guides (photo credit: Matt at Flickr)

The three-phase system has three phase conductors. The system voltage is defined as the RMS voltage between the conductors, also called line-to-line voltage. The voltage between the phase conductor and ground, called line-to-ground voltage, is equal to the line-to-line voltage divided by the square root of three.

The generating station produces the electric energy. The generator voltage is usually around 15 to 25 kV. This relatively low voltage is not appropriate for the transmission of energy over long distances. At the generating station a transformer is used to increase the voltage and reduce the current.

In Figure 1 the voltage is increased to 500 kV and an extra-high voltage (EHV) line transmits the generator-produced energy to a distant substation.

Energy generation, transmission and distribution concept
Energy generation, transmission and distribution concept (click to expand)

The voltage is reduced at the 500 kV/220 kV EHV substation to the high voltage level and high voltage lines transmit the energy to high voltage substations located within cities.

At the high voltage substation the voltage is reduced to 69 kV. Sub-transmission lines connect the high voltage substation to many local distribution stations located within cities. Sub-transmission lines are frequently located along major streets.

Electricity distribution concept

The voltage is reduced to 12 kV at the distribution substation. Several distribution lines emanate from each distribution substation as overhead or underground lines. Distribution lines distribute the energy along streets and alleys.

Each line supplies several step-down transformers distributed along the line.

The distribution transformer reduces the voltage to 230/115 V, which supplies houses, shopping centers, and other local loads. The large industrial plants and factories are supplied directly by a subtransmission line or a dedicated distribution line as shown in Figure 1 above.

All documents, EE software and EE books are free to download.

No. Description Download
1 DC Transmission and Distribution star .
2 Insulator Pollution In Transmission Lines .
3 Energy Transmission and Distribution Guide .
4 Guide to High Voltage Direct Current (HVDC) Transmission .
5 Design and construction of long-distance HV transmission systems .
6 Transmission And Distribution Electrical Engineering .
7 De-icing EHV Overhead Transmission Lines by Short circuit Currents .
8 Guide to Planning of Electric Power Distribution .
9 Handbook for installation of MV lines in rural electricity systems .
10 Guide to power distribution systems for electrical engineers star .
11 Reliability comparison between different 400 kV substation designs New star .
12 Power grid and centralized substation protection and control star .
13 Guidelines for HV circuit breaker function and test methods star .
14 High voltage live work and practices manual star .
15 Transmission substation work practice manual star .
16 A case study on SCADA implementation in 220 kV substation star .
17 Handbook for electrical distribution and transmission fieldworkers star .
18 Guideline for connecting generating plants to the medium voltage network New .
19 General specifications for a customer-owned 69 kV outdoor substation New .
20 Recommended practices for maintenance of LV/MV/HV electrical equipment New .
21 Energy transmission and distribution over lines and cables in power systems New .
22 Experience with commissioning & testing complex busbar protection schemes New .
23 Primary-side protection of distribution substation transformers New .
24 Interconnecting mini-grids (up to 200 kW) with the central electric grid New .
25 Lecture notes on high voltage engineering New .
26 Design and installation of low voltage busbar trunking systems (verified to BS EN 61439-6) .
27 The basics of high voltage cables for underground energy transmission .
28 High voltage safety in marine and other electrical installations .
29 SCADA applications in thermal power plants (TPPs) .
30 Introduction on HVDC transmission systems and HVDC Submarine Power Cables in the World .
31 Voltage drop calculations and design of urban distribution feeders .
32 Fundamentals of High Voltage Circuit Breakers, Switching Stresses and Failure Modes .
33 Medium Voltage DC Applications And Future Scenarios (That Thomas Edison Has Started…) .
34 Operations And Maintenance Of Electrical Power And Distribution Systems .
35 Technical Issues Of Undergrounding High Voltage Transmission Lines .
36 Experience In Implementation Of Relay-Control House For 230 kV Transmission Substation .
37 Construction Techniques In Power Transmission, Hydropower and Photovoltaic Projects .
38 400/220 kV gas insulated (GIS) transmission substation controlled by SCADA .
39 Experience with IEC 61850 in the refurbishment of 380kV power substation .
40 Design And Construction Of Electrical Transmission And Distribution Lines .
41 Implementing Clean Power Plans For Utilities (EPA’s Menu of Options) .
42 Design of Electrical Power Systems for Nuclear Power Plants (NPP) .
43 Offshore Wind Park Connection To an HVDC Platform Without Using an AC Collector Platform .
44 Calculation Of Prospective Short-Circuit Currents On T&D Systems (Practical Guidance) .
45 Transmission Switching Manual For Grid Operators .
46 High voltage facts for undergraduate and postgraduate students of electrical engineering .
47 Class notes on electrical power transmission and distribution (for students, 6th semester) .
48 Technology of High Voltage DC (HVDC) Networks, Their Applications and Problems .
49 Class Notes on Power System Control and Operation .
50 On-shore electrical infrastructure for supplying vessels with electric power in port .
51 Lecture notes on power system engineering for students (6th and 7th semester B.Tech) .
52 Design of SCADA for remote control and operation of wind power plants .
53 The fundamentals of steam power plants .
54 Design of SCADA for remote control and operation of wind power plants .
55 Power systems in deep ocean mining up to 3,500 m .
56 High voltage generation, overvoltages in power grids and insulation coordination .
57 Design and installation of 12 kV gas-insulated load break switch .
58 Design project of 500kV HVDC transmission line from Ethiopia to Kenya .
59 Centralized fault locating system in Vietnam’s power transmission grid .
60 Basic setting of current differential line protection .
60 The basics of Gas Insulated Substation (GIS) for students .
61 Construction of a grid substation for engineers and technical supervisors .
61 The essentials of high-voltage breakdown and electrical discharges .
62 Practical training report on 220/66/11 KV substation .
63 Lecture notes on power station engineering for students .
64 Detailed electrical design of a small hydropower plant (from turbine, generator to transformer) .
65 Short-circuit calculations of the electric power system in a nuclear power plant .
66 Experience in installation of new reactive power compensation on power grid .
67 Transmission and distribution technology overview .
68 High voltage D.C. transmission systems (DC link control, converters & smoothing reactors) .
69 Equipment in electricity distribution networks – Latest developments review .
70 The essentials of AC and DC power distribution systems for students .
71 Powerline carrier (PLC) communication systems in T&D .
72 Notes on electrical power generation, transmission and distribution .
73 Power quality and economics of integration of distributed generation in LV networks .
74 Network operating practice for efficient connection of distributed generation .
75 Handbook on EHV overhead lines and underground cables .
76 Adding capacitor banks to the Sri Lankan transmission network (Analysis) .
77 Finding the best locations and sizes of capacitor banks within an electric network .
78 Analysis of Power Distribution Systems (The impact of distributed generation) .
79 Reliability of the electric power distribution system for 6 alternative loop configurations .
80 Load flow analysis of 138/69 kV substation using ETAP (Electrical Transient & Analysis Program) .
81 Analysis of voltage sags in power distribution networks .
82 Placement and rating planning of feeders & transformers for LV/MV distribution networks .
83 Is DC in distribution grids feasible enough to replace AC? .
84 Improving power quality in low voltage networks with distributed generation .
85 The professor’s lecture notes on transmission lines .
86 Monitoring and detection of partial discharges in stator windings of turbine generators .
87 Improving the voltage quality in distribution systems and wind power generation .
88 Voltage dips as a very important power quality issue .
88 Effects of imbalances and non-linear loads in electricity distribution system .
89 Losses in the transmission and distribution networks and ways to reduce them .
89 Geomagnetic induced current as a severe threat to power systems .
90 Current driven transformers for contactless power supplies in HV lines .
91 Potential energy saving of distribution transformer in distribution network .
92 Design of power converters for HVDC applications .
93 Design of a smart transformer for smart grid with dispersed distributed generation .
94 Connecting LV micro grids to distribution automation .
95 132 kV, 220 kV, 400 kV grids and substation equipment for engineers beginners .
96 Power loss reduction in large urban ring main networks (optimisation, capacitor addition) .
97 Hybrid AC/DC distribution system with a shared neutral .
98 Stability analysis of power network using 600kV, 800kV, and 1000kV HVDC .
99 Real-time corrective control in active distribution networks .
100 Reactive power compensation in the 25kV, 50Hz contact network .
101 Medium voltage networks – Load flow calculation and network planning .
102 The essence of understanding and analyzing distribution power systems .
